Standard Stock Units

PL Custom has Standard Stock Units available for sale. They are built with the same high quality and craftsmanship as a custom designed ambulance.

The Standard Stock Units have quicker deliveries, have consistent and upgraded option content, and come with the same warranties as a custom unit.


Standard Stock Units

PL Custom has Standard Stock Units available for sale. They are built with the same high quality and craftmanship as a custom designed ambulance.

The Standard Stock Unit has a quick delivery, comes with the same warranty as a custom unit, and is available at a lower cost.

PL Custom Standard Features

Please Contact PL Custom or your local dealer for an inventory of available stock units.

The Original PL Custom Standard Stock Units

If you are looking for an affordable ambulance with a quick delivery, then a PL Custom Standard Stock Unit may be the best solution for you. There are two models to choose from. The PL Custom Type l Classic or the PL Custom Type lll Medallion.

PL Type l Classic 170 SSU


Classic Overall Dimensions

  • Overall Length 308” (25’-7”)
  • Overall Width 99”
  • Overall Height 112”
  • Module Length 170”
  • Interior Headroom 72”
  • PL Type lll Medallion 170 SSU


    Medallion Overall Dimensions

  • Overall Length 275” (22’-11”)
  • Overall Width 99”
  • Overall Height 107”
  • Module Length 170”
  • Interior Headroom 72”
  • PL Custom SSU Package Content

    • Trimark power locking automotive door handles w/ keyless entry – compartment doors
    • “E” Full Height Divider with (2) adjustable shelves
    • Super Insulation Package
    • Meganite counter, 1” lip, Left side front Color: Galaxy Mist
    • Meganite counter, 1” lip, Left side rear Color: Galaxy Mist
    • Clear Lexan / Acrylic caninet & doors
    • Single Streetside CPR/Attendant seat with 6 point harness
    • Universal Floor Frame For 170” Classic & Medallion – supports all cot mount requirements
    • Cot mount to be selected by customer
    • Upper Laminate – High Gloss Fashion Grey D381-01
    • Lower Laminate – High Gloss Oiled Soapstone 4882-01
    • Zico Multiversal – set to “M” tank (Specify for Steel M)
    • Power door lock switch, side/rear entrance doors
    • (7) Whelen 900 Series Super LEDs front upper lights
    • Whelen 600 Series directional, front body
    • Whelen KKK Front & Side Body Flashing Lights, CLEAR Lens package
    • Program Flashing Lights to “Single Flash 375”
    • (2) Whelen 900 Series Super LEDs at rear window level

    • Rear Window Level Lights (red w/ clear lens)
    • (2) 700 Series over rear wheels
    • Stop/Tail and Turn Signal-Light heads with clear lenses
    • Back-up, (2) Whelen 600 LED, w/Flange, Max. Intensity
    • Rear Red LED Flasher/Brake Light Priority – rear uppermost corner 900 series
    • Switch in cab On-Off Control. Heater-AC
    • 3-way Dome/Rect. Light Master Switch (Console & LSS)
    • Liquid Spring Control Left Rear Door Open w/Override switch
    • Snow Chain pre-wire
    • Super Auto Eject shoreline (20 amp)
    • Inverter Pre-Wire, Complete-Vanner EMS
    • No additional Paint
    • Reflective Tape 3/4” white, outline, on interior pan of compartment doors
    • Liquid Spring Suspension System (F450)
    • (2) Zico Quick Release Bottle Brackets
    • KKK Compliance Package. Stripe has been deleted from package

    PL Custom Type III Medallion 170 SSU

    The PL Custom Medallion Ambulance

    The PL Custom Medallion Type III has for years set the highest standard for emergency vehicles. The finest fit and finish in the industry is combined with plenty of usable payload and the quietest most comfortable ambulance ride available.

    The PL Custom Medallion Ambulance

  • Overall Length 275” (22’-11”)
  • Overall Width 99”
  • Overall Height 107”
  • Module Length 170”
  • Interior Headroom 72”
  • Image

    PL Custom Medallion Chassis

  • Ford Econoline E-450 Super Duty Chassis
  • 158” WB, 100” CA
  • 14,500 GVW
  • Image

  • 6.8L Triton V-10 gas engine
  • Torque shift 5-speed automatic transmission
  • Ambulance prep package 47A
  • Single 225 amp alternator
  • Dual batteries
  • Interior/Exterior appearance upgrade
  • Four wheel disc brakes with 4 wheel ABS
  • Air conditioning
  • Tilt steering & cruise control
  • AM/FM radio with CD and clock
  • Message center in dash
  • Power windows & door locks
  • Chrome bumper and grille
  • Dual cloth captain’s chairs
  • Daytime running lights
  • LT225/75R 16E tires (7) all season
  • Dual Seal Beam, fixed-lens headlamps
  • Vinyl floor covering
  • Ford OEM trailer tow mirrors/ power adjust
  • Driver and passenger air bags
  • Stabilizer bar front/rear
  • Oxford White YZ
  • PL Custom Medallion Exterior

    Image Image
    Image Image

    PL Custom Type I Classic 170 SSU

    The PL Custom Classic Type I provides the perfect compromise for Fire Department and EMS Personnel. Super Duty for maximum flexibility, durability and payload offer a comfortable and stable ride for the driver, patient and crew.

    Classic Overall Dimensions

  • Overall Length 308” (25’-7”)
  • Overall Width 99”
  • Overall Height 112”
  • Module Length 170”
  • Interior Headroom 72”
  • Image

    PL Custom Classic Chassis

  • Ford F450 Super Duty, 4x4 Chassis
  • 193” WB/108” CA
  • GVW 16,500
  • Ford 6.7 Powerstroke Turbo Diesel V8 diesel engine
  • Image

  • Torque Shift 6-speed automatic transmission
  • Ambulance Prep Package
  • Dual alternators with total amps of 355
  • Dual batteries under hood
  • Ambulance prep package
  • Intelligent oil life monitor
  • Four wheel disc brakes with ABS
  • Air conditioning
  • Front/rear stabilizer bar
  • Front tow hooks
  • Daytime running lights
  • Electronic 4x4 shift on the fly
  • Vinyl floor covering
  • Driver/passenger air bags
  • 40 gallon fuel tank
  • Message center in dash
  • XLT trim level – interior/exterior
  • AM/FM radio with CD and clock
  • High back seats driver/passenger
  • DEF tank mounted on frame rail with body fill
  • LT22570R 19.5 E tires (7) all season
  • Oxford White Z1
  • PL Custom Classic Exterior

    Image Image
    Image Image

    Download our PL Custom SSU Brochure

    Standard Stock Units

    PL Custom Type l Classic Stock Ambulance - Ford F450 4x4


    PL Custom Type lll Medallion Stock Ambulance - Ford E450


    Get our PL Custom Brochure Now!

    Please Contact PL Custom or your local dealer for an inventory of available stock units.
